New drive technology addresses LED efficiency issues

An alternative approach to driving LEDs should ultimately lead to more cost-efficient and reliable LED lighting systems, writes Stewart Hough of Lynk Labs.

Content Dam Leds En Articles 2005 01 New Drive Technology Addresses Led Efficiency Issues Leftcolumn Article Thumbnailimage File
The low voltage (LV) direct current (DC) nature of LEDs makes them easy to integrate in the majority of the electronics products and systems that can readily supply such power from an internal DC source. However, LED power consumption is relatively high in portable devices and there is a continual need to reduce the power consumption of all components in electronic designs, especially in the high growth battery-powered product markets.
Lynkfig1
Figure 1

In contrast, the general lighting and illumination market is heavily built upon a high voltage (HV) alternating current (AC) infrastructure that developed over the last 100 years. This presents a significant challenge in terms of cost, system and lighting product design to effectively interface a LV DC semiconductor into an HV AC infrastructure.

Advances by Osram, Lumileds and other LED manufacturers continue in both lumens per watt (lm/W) efficiency and increased power output to allow LEDs to better compete against legacy lighting. Until now, these advances have been primarily centered on the LED at the semiconductor and device package level. But higher power, even with higher efficiency, presents significant challenges to manage the heat generated by LEDs, since excess heat rapidly degrades the life of the LED.

This has warranted the development of alternative approaches to drive LEDs in order to offer reduction of LED power consumption, improved thermal management, and more cost-efficient and reliable LED lighting systems, enabling LEDs to realize their full potential.

Lynkfig2a
Figure 2a
Lynk Labs, a company based in Elgin, Illinois, USA, has developed such a solution. By looking at the LED from a different perspective, Lynk Labs has adapted classical physics and electromagnetism in a decidedly non-classical way to balance charge flow from a power source to an LED. Lynk Labs is an intellectual property (IP) and product development company with IP related to AC drivers and LEDs that is addressing the heat, product cost, reliability and power efficiency issues faced by LEDs.

Lynkfig2b
Figure 2b
Lynk Labs has now adapted its technology into a new type of LED device and drive method that significantly reduces heat and improves scalability and efficiency while simplifying LED lighting system design. This provides the design flexibility and cost/performance improvements needed to accelerate the use of LEDs in a wide array of applications.

No Return Path

Lynk Labs core technology is No-Return-Path (NRP). The basic principles behind NRP technology fall under Maxwell's theory of displacement currents, which states that when an electric field changes in time, there is a displacement current. There is no need for a DC return path to deliver power to LEDs, OLEDs or other devices. The dipoles in matter and in the electromagnetic vacuum can move back and forth in the presence of a longitudinal alternating electric field. A positive charge moving in the direction of the electric field contributes equally to the current as a negative charge moving in the opposite direction. There does not have to be a net displacement of charge, from left to right for example, to have an electric current flow. LEDs have typically been driven with DC power sources but may be driven with AC more efficiently using NRP based drivers, lamp modules or LEDs.

Lynkfig3
Figure 3
Application of this principle allows for wireless, single wire and hybrid 2-wire delivery of power to LEDs and other loads with significant improvements in cost, scalability, thermal and power management, design flexibility and Lumens per watt.

Lynk Labs is presently applying NRP technology to LED lamp modules and drivers that are compatible with AC utility infrastructures and other sources, including many design approaches for traditional DC power source applications.

All of the possible embodiments of NRP technology are quite far-ranging in scope and application within the electronics product market. Mike Miskin, Lynk Labs president, says the company is initially targeting AC infrastructure applications, including backlighting of LCDs, signage and architectural lighting.

Lynk Labs is now planning an early 2005 release of a new C3LED Lighting System™ to address the design and integration gap that presently exists between LED device makers and lighting product manufacturers.

C3LEDs and LED systems

The C3LED system consists of a lamp module using C3LEDsTM (a new type of LED having an independent driver) LED lamp module and C3D™ drivers. The C3LED lamp modules have independent micro-drivers at each LED that are driven by the C3D driver. As a "dual end solution" it provides a single, scaleable source driver that can drive any LED designed into a C3LED lamp module with total flexibility of the source input. This allows ready mixing and matching of any color-, voltage- or current-specified LED to a single C3D driver.

Lynkfig4
Figure 4
The C3LED Lighting System is the first family of NRP based products intended to provide LED drive electronics and lamp product solutions for signage, backlighting, and legacy lighting systems.

Heat generated by inefficient drivers is transferred to the LED device and directly affects the life and efficiency of the LED. With a C3LED, voltage regulators and resistors are eliminated at the circuit board level within the lamp modules. Because the C3LED system is an improved lighting system solution, it essentially yields a new type of LED with superior cost/performance when driven with C3D AC drivers.

C3LEDs will be available with some of the more popular existing packaged LED products to start with but Lynk Labs is also designing its custom C3LEDs that will be even more optimized for C3LED product and system designs.
