New freedom of creative lighting design: ERCO Compar recessed luminaires

ERCO has developed the new Compar range of recessed luminaires with a striking linear design that delivers light distributions previously restricted to round or square ceiling apertures.

LaserFousWorld Test
LaserFousWorld Test

ERCO has developed the new Compar range of recessed luminaires with a striking linear design that delivers light distributions previously restricted to round or square ceiling apertures. As a result, Compar adds to the design options in typical recessed lighting applications such as foyers, circulation areas or conference rooms in museums, administration buildings, restaurants or galleries whilst also meeting every ergonomic requirement for perfectly efficient lighting solutions in the office environment.

The Compar range of recessed lighting tools is able to implement differentiated lighting concepts in projects requiring a variety of functions and uses. For example, in a large office building areas such as the prestigious foyer, the lift lobby and corridors or the company restaurant need different lighting to the auditorium, conference rooms or shared offices. With its sleek linear aesthetic and integrated technology, Compar offers a wide range of lumen packages with variable distribution options and design details, providing the right lighting tool for every scenario. The result is an economic, creative lighting design based on a reliable and efficient concept.

Slim design with five light distributions

The ERCO luminaire system builds on a modular concept defined by specific parameters creating a logical system that gives the designer flexibility in the combination of different ERCO luminaires. Taking the same approach, Compar is available in the four lengths 4 ¾”, 8 ¼”, 15 6/16” and 29 10/16”, with a width of just 2 1/16”, each with twice as many LED lenses – and double the luminous flux – as the previous one. Thus, it results in outputs from 630lm to a powerful 6600lm for high illuminances particularly in high rooms.

Extremely efficient lenses specially developed by ERCO shape the light of the LED modules into the rotationally symmetrical light distributions wide flood and extra wide flood, the asymmetrical light distribution wallwash for uniform vertical illuminance, and the two axially symmetrical distributions oval flood and oval wide flood. The new oval wide flood answers the stringent standards of workplace lighting.

Ergonomic office lighting in a striking linear design

In contrast to the oval flood lens which is designed in true alignment with the luminaire for the efficient illumination of corridors, ERCO has developed the new oval wide flood distribution particularly for office workplaces of high-quality design. It features high cylindrical illuminances and a good vertical uniform illumination. The extra wide flood lens, meanwhile, allows the luminaires in areas such as circulation zones or foyers to be spaced unusually far apart – saving both investment and operating costs.

Details that make the difference

The downlight characteristics of Compar are complemented by the powerful lens wallwashers adding vertical illuminance as an essential component of perception-orientated lighting design in a linear system. Compar recessed luminaires are supplied with a covered mounting detail. Flush mounting frames are available as accessories, as are louvres in silver or black to enable Compar to blend with the architecture and ceiling design. Light colors include warm white (3000K, CRI≥90) and neutral white (4000K, CRI≥80), and on request LEDs with 2700K, CRI≥90 and 4000K, CRI≥90, with control gear options covering phase dimmable and 0-10V versions.

Offering a set of tools for a wide variety of lighting solutions, Compar presents itself as the new powerhouse for linear aesthetics in the ERCO product range – making it a welcome alternative to round and square downlights in recessed lighting concepts and to conventional linear luminaires and fluorescent lamps for the illumination of workplaces.

Technical features

ERCO lens system: Spherolit lens, collimator made of optical polymer, light distributions: wide flood, extra wide flood, oval flood, oval wide flood, wallwash

ERCO LED module: High-power LEDs on metal-core PCB,

light colors: warm white or neutral white, 2700K CRI≥90*, 3000K CRI≥90, 4000K CRI≥80 and 4000K CRI≥90* (* light colors on request)

Louvre: Polymer, silver or black

Housing: Aluminum, four sizes

Mounting: With mounting detail made of polymer, covered or flush (accessory)

Control gear: Dimmable (trailing edge or 0-10V)

001 Erco Compar

Compar offers an elegant and space-saving alternative to round or square recessed luminaires. From a photometric aspect, the new ERCO lighting tools stand apart with superior quality and efficiency. Image: © ERCO GmbH, www.erco.com

002 Erco Compar

Compar is available in the four lengths, resulting in outputs from 630lm to a powerful 6600lm for high illuminances particularly in high rooms. Image: © ERCO GmbH, www.erco.com

003 Compar 101

With its linear aesthetic, Compar gives the designer enormous creative scope in ceiling design, whilst the five efficient light distributions of the ERCO recessed lighting tools meet the highest standards of distinctive architectural and office lighting. Image: © ERCO GmbH, www.erco.com


About ERCO

The ERCO Light Factory in the German town of Lüdenscheid is a leading international specialist in architectural lighting using LED technology. The family business, founded in 1934, now operates as a global player with independent sales organizations and partners in 55 countries worldwide. Since 2015 ERCO’s portfolio has been 100% LED. With this in mind, ERCO in Lüdenscheid develops, designs and produces digital luminaires with focus on photometrics, electronics and design. Working closely with architects, lighting designers and engineers, ERCO develops lighting tools used primarily for applications in the following fields: Work, Shop, Culture, Community, Hospitality, Living, Public and Contemplation. ERCO understands digital light as the fourth dimension of architecture – providing highly precise and efficient lighting solutions to support creative designers in turning their visions into reality.
