LEDs provide light messaging on Nokia 3220

Nokia's new 3220 camera phone, unveiled at a snowboarding festival in Greece, features an innovative use of LEDs to provide a messaging function.

Jun 14th, 2004
Content Dam Leds En Articles 2004 06 Leds Provide Light Messaging On Nokia 3220 Leftcolumn Article Thumbnailimage File
Nokia 3220
The phone has a color screen backlit with LEDs, a built-in camera that uses white LEDs to provide the flash function, and transparent "Nokia Xpress-On" grips on the side. The grips contain LEDs that pulsate with light effects to indicate calls and messages, and in sync with the beat of ringtones.
Fun Shell

When a "Fun Shell" is added to the phone it becomes capable of wave messaging. The shell has a strip of 12 orange LEDs operating at 590 nm with a brightness of 45 mcd. When the phone is waved from side to side, the LEDs appear to "write" a message that floats in mid-air. Nokia claims that the images, which can be personalized or chosen from an archive, can be viewed from up to 6 meters away.

The Nokia 3220 is a tri-band camera phone that will be available in two versions: a GSM 900/1800/1900 primarily for the European and Asian markets, and a GSM 850/1800/1900 primarily for the Americas. Shipments are expected to start in summer 2004.
