Jesco Lighting offers aimable, dimmable ML1 LED Modulinear lighting fixture

Content Dam Leds En Ugc Iif 2014 03 Jesco Lighting Offers Aimable Dimmable Ml1 Led Modulinear Lighting Fixture Leftcolumn Article Thumbnailimage File
40228 0 thumb Date Announced: 18 Mar 2014

New Product Introduction: ML1 LED Modulinear -- new family of aimable, dimmable recessed ceiling fixtures with one to four LED modules. Each module incorporates a single 20W high output COB (chip-on-board) LED.

Design: JESCO Lighting Group In-House Product Design and Engineering Team.

Manufacturer: JESCO Lighting Group, founded 1998.

Product Applications: ML1 LED Modulinear -- a contemporary, integral, design-homogenous family of energy-saving recessed ceiling fixtures in four models. Each provides aimable, dimmable pure-white downlighting from sleek low-scale units, yielding LED lighting with design continuity.

ML1 designs are well suited for lighting (or showcasing) of freestanding merchandise floor displays; merchandise wall shelves, clothing racks, mannequins; accent/ambient or spot lighting in galleries; highly upscale merchandise showrooms; galleries and museums; dining and hospitality venues; upscale retail; in building entryways, lobbies, waiting rooms; corridors, and other commercial, institutional or discriminating residential interiors.

Product Description: ML1 LED Modulinear is an unobtrusive, recessed ceiling module with a choice of integral ceiling trims, or trimless. Each ML1 module incorporates a single 20W high-output COB LED, with a choice of narrow, medium or wide beam spread reflectors in 2700K, 3000K and 4000K color temperatures which are all field-chaneable. Modules are universally adjustable to eliminate dark spots or too-sharp cutoffs. They are available in trim or trimless configurations, and are suitable for both dry and damp locations.

Construction & Finishes: ML1 LED Modulinear units are constructed from sturdy but lightweight cold-rolled steel housings, with a separate wiring compartment for assured long-term operating safety and convenience. Housings have a matte black or matte white high-temperature powder-coat painted finish; housing trims have a choice of matte black, matte white or silver finishes. All ML1 LED modules are 7.5625-inches wide by 6.625-inches high. Module lengths are one light, 7.625 inches; two lights, 13.125-; three lights, 20.125-; or four lights, 27.125-.

Each 20W high-output COB LED emits an impressive high CRI 1726 lumens. An advanced heat-sink design provides superior thermal management for 50,000-hour operation at 70% lumen maintenance. ML1’s universal 120-277 VAC LED driver delivers a high-power-factor above 0.90, is 0-10V dimmable, and incorporates a self-resetting thermal protector prevents overheating. ML1 LED has a double-gimbal design that allows wide adjustability and the ability to lock modules into position. Butterfly-style mounting brackets provide up to 5-inches vertical adjustment and accommodate EMT conduit. All models are c-CSA-us listed with a 5-year factory warranty.

JESCO Lighting Group +1-800-527-7796 or +1-718-366-3211
