OPTEK DEVELOPS 0.5W LED PACKAGE FOR SINGLE AND ARRAY APPLICATIONS

Content Dam Leds En Ugc 2007 05 Optek Develops 0 5w Led Package For Single And Array Applications Leftcolumn Article Thumbnailimage File
15132 0 thumb Date Announced: 08 May 2007

NEW YORK, NY (May 8, 2007) – Providing lighting design engineers with an energy-

efficient, high luminance, compact solid-state light source, TT electronics OPTEK

Technology has developed a 0.5W surface mount white LED package. Designated the

OVS5WBCR4 Series, the device features an ultra-low profile of just 1.5mm.


“The exceptional spatial uniformity and full 120° viewing angle make this packaged LED

suitable for both single use and array applications,” said Richard Saffa, vice president of

OPTEK Technology’s Visible LED Business Unit. “The small size of the OVS5WBCR4

package also allows it to be specified for specialized applications in which larger devices

would not be suitable and where high-power devices are not required.”


Applications for the OVS5WBCR4 Series LED package include conventional lighting,

electronic signs and signals, automotive interior and exterior lighting, architectural indoor

and outdoor lighting, and general illumination.


The 0.5W white LED package features a water clear lens and 120° viewing angle. Typical

luminous flux is 21 lumens, with a typical on-axis intensity of 8.5cd and a typical forward

voltage of 3.2V. DC forward current is 180mA, with peak pulsed forward current of

500mA. Power dissipation is 700mW and maximum rated junction temperature is 125°C.

Operating temperature range is -40°C to +100°C. OPTEK also offers optional optics to

suit specific applications where focused beam patterns are required.


The OVS5WBCR4 LED package measures 6mm x 6mm, with a height of 1.5mm.

The OVS5WBCR4 package is compatible with standard Sn/Pb as well as Pb-free reflow

soldering processes.


Typical pricing for the OVS5WBCR4 LED package starts at $1.00 each in quantities of

10,000. Production quantity lead times, if stock is not available, are from 7 to 9 weeks.


For more information on the OVS5WBCR4 surface mount LED package, contact TT

electronics’ OPTEK Technology at 1645 Wallace Dr., Carrollton, TX, 75006; call 972-323

-2200, or visit OPTEK on the Web at http://www.optekinc.com/products/VLED_smd.asp.

In Europe, contact JP Delaporte at info@optek-europe.com or call +1-972-323-2333. In

Asia, contact T.H. Swee at thswee@optekasia.com or call +852-9190-4641.

Contact
Janie Haynie, Product Marketing Director OPTEK Technology 972-323-2200 jhaynie@optekinc.com

E-mail:bgaddy@btbmarketing.com

Web Site:www.optekinc.com
