Toshiba’s latest LED driver integrates brightness control, PWM grey scaling and protection

Content Dam Leds En Ugc 2010 01 Toshiba S Latest Led Driver Integrates Brightness Control Pwm Grey Scaling And Protection Leftcolumn Article Thumbnailimage File
20966 0 thumb Date Announced: 26 Jan 2010

High accuracy 16-channel driver delivers constant currents, 256-step brightness control and 65536-step grey scale control

Düsseldorf, Germany, 26th January, 2010 - Toshiba Electronics Europe (TEE) has announced a 16-channel LED driver that combines comprehensive brightness control with a built-in PWM grey scale capability. The TB62721 is ideal for traffic signs, information boards and other high quality large panel displays requiring the accurate and reliable control of multiple colour LEDs.

The new driver can deliver output voltages of up to 38V and provide constant currents of between 2mA and 80mA per channel using just a single resistor. All of the functionality needed to deliver 256-step output brightness control is integrated into the device, while the on-board PWM capability provides 65536-step grey scale control per channel.

Both the output-to-output accuracy and IC-to-IC accuracy of the TB62721 is 1.5%. This allows large displays based on multiple LED chains and drivers to maintain consistent brightness levels within very tight tolerances.

Designed for secure, reliable operation, the TB62721 features on-board protection including thermal shutdown, output open and short-circuit protection, and Power-on-Reset.

The TB62721 is supplied in a SSOP24 package and can operate with input voltages ranging from 3.3V to 5.0V. Interfaces are fully BiCMOS-compatible and the device can handle serial input data rates to 30MHz.

###
