Diodes' LED driver reduces size and cost of lighting products

Content Dam Leds En Ugc 2010 01 Diodes Led Driver Reduces Size And Cost Of Lighting Products Leftcolumn Article Thumbnailimage File
20908 0 thumb Date Announced: 20 Jan 2010

Dallas, Texas - January 19, 2009 --- Diodes Incorporated has introduced
a 1 Amp rated linear mode constant current LED driver specifically
designed to reduce the size and cost of a range of general illumination
products, including flashlights and lighting in emergency, garden, and
poolside applications.

Packaged in an optimized small footprint, low profile DFN package, the
highly integrated DLD101 LED driver provides designers with significant
board space savings, with the package's high thermal efficiency assuring
higher power dissipation than comparable SOT23 ICs.

By integrating a unique 'base accessible pre-biased transistor', DLD101
has been able to incorporate biasing resistors on chip, meaning LED
current setting is now via a single external resistor, without the need
for an additional boost transistor. For the pass element, a high drain
current 60V N-channel MOSFET has been used instead of a bipolar
transistor to reduce overall bias current.

As well as reducing the PCB size and external component count of
alternative LED driver solutions, the DLD101 also completely removes the
EMI signature associated with switching regulator solutions.

The DLD101 1A linear mode constant current LED driver is priced at $0.25
each in quantities of 10K. For more information, the datasheet is at:
http://www.diodes.com/datasheets/ds32007.pdf

PR ref: DI0594
