Shenzhen KMTEKLED announces full color LED display

Content Dam Leds En Ugc 2010 08 Shenzhen Kmtekled Announces Full Color Led Display Leftcolumn Article Thumbnailimage File
25256 0 thumb Date Announced: 11 Aug 2010

Display and control and structure features

Pixel Pitch 16 mm
Module size 256 mm*128 mm
Pixel composing 2R1G1B
Display resolution/module 16 dots*8 dots
Wavelength (R) 625±5
Wavelength (G) 522±3
Wavelength (B) 465±5
Wave Angle (H) 120°(H)/ 60°
LED package DIP546
Standard cabinet size 1024 mm*768 mm
Weight per sqm 65 Kg/sqm
Protection classification --- IP65
Install mode Wall mount, hung and stand structure
Density 3,906
Working power
Display color 256*256*256
Whiteness brightness ≥5500cd
Working voltage AC 220v/380v±10% 47~64Hz
Brightness level 128 grade
Max power/sqm 1600W/sqm
Changing frame frequency 60 Hz
Average power/sqm 1100W/sqm
Refresh 400 Hz
Short circuit protection Yes
Driving method Constant Static current
Control mode synchronous
Display port DVI
Display mode 1024*768 /1024*1024
Environment Outdoor
Out of control 1/10,000 ( scattered)
Working temperature --20~50 degree
lifetime 100,000 hours
Working Humidity 10~90%

Best regards Tina Chow Shenzhen KMTEKLED Photoelectricity Co., Ltd. Tel: 86-755-86590726 Fax: 86-755-86670400 Email: or
