Shenzhen Green Lighting's square LED panel (7W, 960lm, 180*180*13mm)

Aug. 18, 2010
Date Announced: 18 Aug 2010 LED Panel / Square LED Panel (7W,960lm,180*180*13mm), CE, FCC, RoHS approved, can be used to replace conventional downlight lamp Model No: GL-TDC-F7 1. Dimension: 180*180*13mm2. Power: 7W3. Operating Voltage: DC24V4. Input Voltage: AC100V~AC240V available5. Light source: low power SMD LED6. Uniformity of lighting efficiency: ≥95%7. Color Rendering Index (Ra): > 808. Color temperature: 2700K-6500K (Optional, according to your requirement)9. Luminous: 960lm; Lux: 1m=130Lux; 1.5m=75Lux; 2m=50Lux10. Material: superior aluminum alloy and high quality lumisheet acrylic plate (PMMA). 11. Edge light methods, with advanced light guide technology.12. Low heat, and more enviornment protection (energy saving up to 50%).13. No stroboscopic, no pollution, long lifespan, low luminous decay. 14. Quickly start (0.01second) and the light is natural and soft, appearance is exquisite, 15. CE, FCC & ROHS approved, with independent wide range AC adapter.16. Lifespan: ≥50000h (8 years using validity)17. Installation: flush bonding. Application: Replacement for conventional downlight lamp in Hotels, Conference / Meeting rooms, Offices, Commercial Complexes, Residential / Institution Buildings, Schools, Colleges, Universities, Hospitals, etc.

Mr. James Wu Shenzhen Green Lighting Co., Ltd. Skype: gl.light MSN: [email protected] Phone: 86-755-86372662 ext. 812 Fax: 86-755-86372040 Mobile: 86-13760215716

E-mail:[email protected]
