AVX's 9296 Series contact system provides stability, wire retention in industrial and SSL applications

Content Dam Leds En Ugc 2013 09 Avx S 9296 Series Contact System Provides Stability Wire Retention In Industrial And Ssl Application Leftcolumn Article Thumbnailimage File
Date Announced: 13 Sep 2013

AVX Corporation recently introduced a unique new surface-mount, single-poke, dual-beam boxed contact system designed to enable simple, reliable, and solderless wire termination in industrial and solid-state lighting applications.

The novel, single-position, 9296 Series contact integrates several key features within the stamping to facilitate SMT pickup, wire guidance, high force retention, and easy wire removal, effectively providing all of the benefits of a full-function connector in an insulator-free solution, mitigating both labor and materials costs, as well as contributing to smaller and more cost-effective end-designs.

AVX's new 9296 Series single-poke, dual-beam boxed contact system enables single-contact placement, significantly expanding design functionality in a host of ruggedized wire-to-board applications. Featuring an enhanced solder pad for maximum mechanical stability on the PCB and a unique closed-box design that captures wires from all sides, providing outstanding wire retention, 9296 Series contacts are capable of accepting 12-20AWG solid and stranded wires and are rated for 10-20A depending on AWG. Voltage rating for the series is dependent upon placement distance.
