Seoul offers power LED solutions for high brightness lighting

Jul 20th, 2005
Content Dam Leds En Ugc 2005 07 Seoul Offers Power Led Solutions For High Brightness Lighting Leftcolumn Article Thumbnailimage File
Date Announced: 20 Jul 2005

Easy-to-design second optic lens with P3 Z-Power LEDs

SSC’s Z-Power P3 series are specifically designed with 130-degree viewing angle (white: 120 degrees) of Lambertian emission LEDs. The P3 Z-Power LED is SMT (reflow) solderable, and has an excellent thermal resistance. The P3 Z-Power series of high-power LED packages, which includes a package containing eight high-power red, green, blue, white, warm white, amber, cyan, and royal blue chips.

The White P3 Z-Power LED has a luminous flux of 200 lm at 1.4 A (5W), corresponding to 40 lm/W, while the luminous efficacy is 52 lm/W at 350 mA. The correlated color temperature (CCT) for white is given as 2,650-10,000 K, while the reliability (time to the reach 50% degradation of lumen output) is stated as 70,000 hours at 350mA.

More information on the P3 Z-Power series visit: http://www.ledsmagazine.com/articles/news/2/7/17/1

World's first innovative full-color power LED solution

Z-Power P1 series of high-power LED includes a package containing three high-power red, green and blue chips.

The white Z-Power LED has a luminous flux of 140 lm at 1.4 A (5 W), corresponding to 28 lm/W, while the luminous efficacy is 40 lm/W at 350 mA. The Z-Power LED is available in white, red, green, blue, amber, cyan, warm white and full color. The range of radiation patterns includes 40°, 70° and 130°, as well as a side-emitter version. The Z-Power LED is SMT(Reflow) solderable, and has an excellent thermal resistance of 16 °C/W. Several versions operating at 1 W (350 mA), 2.5 W (700 mA) and 5 W (1.4 A) are available.

More information on the P1 Z-Power series visit:
http://www.ledsmagazine.com/articles/news/2/7/17/1

Contact
Chang Joon Ko Marketing Analyst, Seoul Semiconductor 148-29, Gasan-Dong, Geumcheon-Gu, Seoul, Korea, 153-801 Tel: +82 (2) 2106-7334, Fax: +82 (2) 858-5537

E-mail:changko@seoul-semicon.co.kr

Web Site:http://www.ledsmagazine.com/articles/news/2/7/17/1
