Lumileds Boosts Intensity of CoBs for Spotlights and Downlights

Nov. 11, 2019
Featuring brilliant light with greater punch, efficacy and reliability than competing products, the LUXEON CX Plus COBs enable exceptional spotlights, track lights and PAR lamps.

San Jose, CA – Lumileds introduced three lines of CoBs: the LUXEON CX Plus CoB (Gen 2), LUXEON CX Plus CoB – High Density and LUXEON CX Plus CoB – High Density (Below BBL), drop-in upgrades for Lumileds and competing arrays. The second generation arrays feature industry leading performance and a 14% flux improvement vs. the previous generation. Delivered in a range of light emitting surfaces (LES) (4.5, 6, 12 and 14mm) and correlated color temperatures of 2700K to 5000K, the Gen 2 arrays provide excellent efficiency of above 140 lm/W at 3000K 80CRI or 122 lm/W at 3000K 90CRI.

The High Density version of LUXEON CX Plus CoB provides industry leading punch (center beam candle power) and is available in on-black body locus (BBL) coordinates for halogen-like illumination or below-BBL for ceramic metal halide-like illumination. The LUXEON CX Plus CoB – High Density provides up to 1,150 lumens at 3000K 90CRI from the smallest LES of 4.5mm. Flux is 10% higher than competing CoBs at 6mm and 9mm LES. Offered in three LES (4.5, 6 and 9mm) on 13.35mm x 13.35mm substrate, the arrays cover a range of color temperatures (2700K to 5000K) with a minimum of 80CRI or 90CRI and color control within 3-step or 2-step MacAdam ellipse. For the Below-BBL versions, color temperature range is 2700K to 4000K at a minimum of 95CRI with color control within 3-step or 2-step MacAdam ellipse. “The below black body option is perfect for illuminating artwork, for instance, because the highest color fidelity combines with slightly more saturated colors for stunning results,” said LP Liew, Product Manager of LUXEON CoBs.

All LUXEON arrays utilize a metal core PCB substrate that is more resistant to cracking during luminaire assembly. The low resistance of the MCPCB also provides superior removal of heat from the LED, leading to smaller heatsinks and more compact luminaires.

 For more information on the LUXEON CX Plus CoB (Gen 2), LUXEON CX Plus CoB – High Density and LUXEON CX Plus CoB – High Density (Below BBL) see LUXEON CX Plus CoB (Gen 2) at, LUXEON CX Plus CoB - HD at, and LUXEON CX Plus CoB - HD (Below BBL) at
