HTI's IP66-rated canopy lights achieve more than 130 lm/W LED efficiency

Content Dam Leds En Ugc Iif 2014 03 Hti S Ip66 Rated Canopy Lights Achieve More Than 130 Lm W Led Efficiency Leftcolumn Article Thumbnailimage File
40186 0 thumb Date Announced: 05 Mar 2014

HTI introduces its brand new LED canopy light equipped with Philips Lumileds chip and Philips Advance power supply. It is IP66 rated, explosion-proof, and comes with a 5 year warranty. IES files are available. An integrated modular design supports excellent heat sinking and easy replacement for future maintenance. The power supply is built in the chamber with better protection than external ones.

Technical data:
LED chip: Philips Lumileds (LM80 test report available)
Power supply: Philips Advance (UL, CSA, CE, RoHS, ENEC05 approved)
Input voltage: 120-277Vac; 50/60Hz
LED efficiency: Greater than 130Lm/W
Lamp efficiency: Greater than 98Lm/W
IP rating: IP66
Power factor: Greater than 0.95
CRI: Ra greater than 70 (Optional: Ra greater than 75)
CCT: 5000K (Optional: 3000K, 4000K, 6000K, etc)
Warranty: 5 years for the whole lamp
Light distribution: Symmetric (Optional: asymmetric)
Housing color: White
IES files: Available

About HTI LED:
HTI LED is a professional manufacturer of high quality LED lighting products which have been exported to more than 30 countries. Our optimized LED lights are widely used in project, commercial, and industrial lighting. If you would like to know more about our products such as LED canopy lights, street lights, tunnel lights, flood lights, high bay lights, and high mast lights, please visit our website:

Jack, manager - Global Business Dept, Shenzhen Hitec Lighting Co., Ltd +86-755-3632-8012
