PicoLED™ - the smallest, thinnest full-color LEDs (SML-P12 series)

Content Dam Leds En Ugc 2007 03 Picoled The Smallest Thinnest Full Color Leds Sml P12 Series Leftcolumn Article Thumbnailimage File
14996 0 thumb Date Announced: 26 Mar 2007

ROHM Co., Ltd. completed the development of an ultra-compact LED featuring both the smallest volume and area offered. The SML-P12 series (PicoLED™) is ideally suited for devices requiring thin, compact components, such as mobile phone keypads, small dot-matrix units, and compact seven-segment display devices.

Utilizing original high luminosity device and ultra-precise processing technologies has enabled ROHM to develop the SML-P12 series (PicoLED™) of ultra-compact, ultra-thin chip LEDs (t = 0.008 in) in a full range of colors - previously thought to be impossible due to the significant loss in luminosity with traditional LEDs.

The units feature the same level of brightness as conventional chip LEDs, but in a package size 53% smaller in area and with 74% less volume than standard 0603-sized products. This makes them ideal for use in high density applications with narrow spaces, contributing to greater set miniaturization.

The LEDs can also be used to create compact, full-color high-density matrices (0.06 in pitch) that can be used in car audio displays or to produce seven-segment displays with a character height of 0.2 in (an industry first), broadening the possibilities of numerical display applications.

A full line-up is available in a variety of colors: red, orange, yellow, green, blue, and white, and all of the light-emitting elements are of the high-reliability four-element (InGaAlP) or high-luminosity (InGaN) type, ensuring continuous, long-term, reliable operation.

Pricing and availability:
Sample pricing for SML-P12 is $0.80 each and mass production is scheduled to begin April 2007. Lead time is 10-12 weeks ARO.

Applications:
Mobile phone keypads
Small dot-matrix units
Compact seven-segment display devices

SML-P12 PicoLEDTM Features:
Ultra compact (0.04in × 0.02in)
- 53% smaller area and 74% less volume than conventional 1608-sized units
High-luminosity types offered in a range of colors
- red, orange, yellow, green, blue, and white
