Avago Technologies enters high-power LED market with first series of low-profile LED packages

Content Dam Leds En Ugc 2006 06 Avago Technologies Enters High Power Led Market With First Series Of Low Profile Led Packages Leftcolumn Article Thumbnailimage File
13301 0 thumb Date Announced: 23 Jun 2006

Avago Technologies enters high-power LED market with first series of low-profile LED packages for portable and architectural lighting

-- Low Thermal Resistance and Moisture Sensitivity Levels Make 1-Watt LED Package More Reliable and Easier to Install

Avago´s ASMT-MX00 LED

Avago Technologies, the world’s largest privately held semiconductor company, recently announced its first series of 1-watt, high-power LEDs in one of the thinnest packages available. This new LED offers brighter illumination, more reliability than competing products and can be installed easily.

Avago’s ASMT-MX00 is ideal for use in applications that require ultra-high-brightness LEDs, such as flashlights, reading lamps, architectural and garden lighting. This offering can lead to new lighting applications, such as brilliantly-backlit signs no thicker than a picture frame.

Avago’s new ASMT-MX00 LED package provides manufacturers with two significant advantages. First, it can be easily soldered using conventional surface mount (SMT) techniques to minimize production costs, and the package is qualified to a JEDEC moisture sensitivity level (MSL) rating of 2A.

For manufacturers, this rating means that the ASMT-MX00 LEDs can be kept in the open air (30° C, 60 percent relative humidity) for up to four weeks after being removed from their sealed package without the need to remove absorbed moisture.

“Avago has entered the 1-watt LED market to provide our customers with a unique product combined with the assurance of our industry recognized reliability and ability to deliver in volume,” said Cheng Kai Chong, worldwide marketing manager for Avago Technologies' Optoelectronic Products Division.

“Our ASMT-MX00, which is the first in a series of 1-watt LED products, provides customers with one of the thinnest packages available, superior heat dissipation, compatible to IR soldering, robust moisture resistance and encapsulated in heat and UV-resistant silicone compound.”

The ASMT-MX00 series of 1-watt continuous power dissipation indium gallium nitride (InGaN) LEDs are available in blue, green and phosphor white, and feature a smooth radiation pattern with a 120-degree viewing angle (110 degree for white).

Features

• The dimensions of the ASMT-MX00 surface mount power package are 8.5 mm wide by 15.85 mm long by 3.3 mm high.
• Features an exposed pad design to provide low thermal resistance (10 C/W) between the LED chip junction and printed circuit board to minimize temperature rise and help assure long-term device reliability.
• LED chip is encapsulated in a silicone compound to assure resistance against UV and heat exposure , the packaged LEDs are specified for operation over the –40° C to +85° C temperature range, and are capable of withstanding electrostatic discharge (ESD) levels of 16 kV (class 3b) per ESD Association standard ESD STM5.1, Electrostatic Discharge Sensitivity Testing -- Human Body Model.
• Color temperatures from approximately 4500 to 5600, 5600 to 7000 and 7000 to 10,000 K are available.
• Typical total luminous flux of 40 lumens (green), 10 lumens (blue) and 35 lumens (white), respectively (at 350 mA forward current).
• Pb-free and RoHs compliant.

U.S. Pricing and Availability

The ASMT-MX00 series 1-watt LEDs are priced in the $2 range (depending on color) in small to moderate quantities. Samples and production quantities are available now through Avago’s direct sales channel and worldwide distribution partners.
