LEDiL qualifies lenses for use with new Cree XLamp XT-E LED

Content Dam Leds En Ugc 2012 02 Ledil Qualifies Lenses For Use With New Cree Xlamp Xt E Led Leftcolumn Article Thumbnailimage File
34300 0 thumb Date Announced: 18 Feb 2012

LEDiL announces the availability of 33 lenses qualified for use with Cree’s new XLamp® XT-E White LED, which Cree promotes as delivering twice the lumens-per-dollar of other LEDs.

The wide-range of lens styles offered by LEDiL provides multiple design choices and beam patterns in the quest to drive higher performance and reduced system cost. Use of secondary optics characterized for a specific LED and engineered to provide usable light only where needed helps to reduce the number of LEDs required in a lighting system, which leads to smaller power supplies and heat sinks and reduced system cost.

Available single-position TIR (total internal reflection) lenses include 16.1 mm, 21.6 mm, 26 mm and 35 mm outside dimension, with FWHM beam angles from 9 degrees through 60 degrees, plus one lens with a 35x16 oval beam pattern.

These lenses address almost all lighting needs and are often deployed in wide-area illumination, cove and wall-wash, task lighting and indoor effect lighting. Three-position lens arrays in 35 mm and 40 mm, which achieve beam angles between 12 degrees to 36 degrees FWHM, are ideal for development of highly efficient MR-type spot lights used in retail, hospital, museums and supermarket lighting.

Designers of street lights, parking lot and garage lights, and high bay and similar commercial lights can choose from five different STRADA lenses that offer asymmetric light distribution patterns. Under-cabinet and interior mood lighting is also enabled with the performance of XT-E LED and LEDiL’s range of optical solutions.

“The rapid adoption of lighting-class LEDs as superior alternatives to traditional, energy inefficient or environmentally unfriendly light sources such as incandescent, halogen and fluorescent bulbs requires a good selection of secondary optics,” said Robert Derringer, LEDiL Director of Business Development.

“Swift introduction of optics when new LEDs are released to the market remains a top priority for LEDiL as we help to expand the markets and applications served by Cree. And, if our standard offering of products – which now approaches 1000 different lenses and reflectors – does not meet market needs, LEDiL is willing and able to support rapid deployment of modified or custom solutions.”

LEDiL’s designers engineer precision optics that provide 90% or higher efficiency, with good beam cut-off and color consistency. Outdoor applications benefit from LEDiL’s use of UV-stabilized, optical-grade PMMA. This material, which has outstanding resistance to ultraviolet radiation, also offers good resistance against scratches and other effects of outdoor exposure. Ease-of-use is achieved, in many cases, with molded location pins for precise mounting and pre-installed mounting tape.

ABOUT LEDiL Oy

The only true specialist in the field of secondary optics for high-power and lighting-class LEDs, LEDiL has been producing precision-engineered optics and reflectors since 2002 and now boasts nearly 1000 standard products optimized for use with LEDs produced by the world’s prominent LED manufacturers. Custom solutions are also commonly developed with minimal end-user tooling investment required. With production in Finland and China and a global network of authorized distributors, LEDiL’s products are market-competitive and readily available.

Contact
Robert Derringer Director, Business Development +1.908.216.2377

E-mail:bob.derringer@ledil.com

Web Site:www.ledil.com
