Optical Research Associates' LightTools 6.1 software for design/analysis

Content Dam Leds En Ugc 2008 05 Optical Research Associates Lighttools 6 1 Software For Design Analysis Leftcolumn Article Thumbnailimage File
16218 0 thumb Date Announced: 07 May 2008

The newest release of LightTools® illumination design and analysis software from Optical Research Associates (ORA®) delivers a number of advanced modeling and analysis features that facilitate the design of sophisticated luminaires, LEDs, and displays. For example, LightTools 6.1 includes a new Ray Path feature that makes it easy to identify exactly what system elements are contributing to light loss, scatter, unintentional reflections, or ghost images. This is particularly useful in the design of stray-light sensitive systems, such as microlithography steppers or astronomical instruments.

LightTools also now supports accurate modeling of scattering surfaces by allowing users to apply measured BSDF data (both isotropic and anisotropic) to a surface. Additionally, the software comes with a library of BSDF data of reflective materials most commonly used in luminaire construction, including those available from companies such as Alanod and Almeco. Support for gradient index (GRIN) lenses has also been added, including radial, axial, spherical, and user-defined gradients.

Accurate modeling of LEDs with LightTools has been further extended with new ways to specify the properties of phosphors. In particular, the mean free path (the average distance that a ray will travel in a material before striking a phosphor particle) can now be described as a constant, as a wavelength-dependent quantity, or by using Mie scattering theory.

Finally, LightTools’ ease of use has been enhanced with expanded foreign language support. Specifically, program menus and dialog boxes are now available in French, German, Simplified Chinese, Traditional Chinese, and Korean, in addition to Japanese, which has long been included in the software.

With 45 years of success as an industry leader, Optical Research Associates (ORA) is committed to delivering innovative solutions to the optics industry. With its CODE V® and LightTools software products, ORA is the world’s leading developer of optical software. ORA is also the largest independent supplier of optical design and illumination engineering services, with more than 4,500 completed projects since the company was founded in 1963.

Contact
David Brown Vice President of Sales and Marketing Optical Research Associates 3280 E. Foothill Blvd. Pasadena, CA, 91107 ph 626 795-9101 fax 626-795-0184.

E-mail:info@opticalres.com

Web Site:www.opticalres.com
