The BINAY PowerLED inspection hand lamp provides a long-life and reliable solid-state illumination solution for industrial work inspection illumination applications

Content Dam Leds En Ugc 2011 04 The Binay Powerled Inspection Hand Lamp Provides A Long Life And Reliable Solid State Illumination S Leftcolumn Article Thumbnailimage File
31309 0 thumb Date Announced: 02 Apr 2011

BINAY PowerLED Inspection Hand Lamps utilize a light source comprised of multiple high power white LEDs, and offer the following benefits:

• Very low power consumption – only 6-9 watts
• Long life (over 50,000 burning hours), which ensures zero maintenance costs; covered under 3-year warranty
• Greatly reduced fire hazard; As the light source is non-incandescent in nature, the unit does not heat up even with prolonged use
• Completely shock proof, as the light source is comprised of solid state power light emitting diodes, with no filament to break
• Cool light output, with no heat radiation; NO infra-red or ultra-violet radiation
• Light and portable; robust and sturdy design
• Directional light, focusing only on the work area, thus no glare to the eye
• Low voltage (24V) operation at light source possible; no danger of electric shock
• Environment-friendly operation (as they contain no mercury or heavy metals, as in fluorescent lights)

Being light and portable in design, the BINAY PowerLED Inspection Hand Lamp is ideal for use in work inspection illumination in the factory. The light output pattern is designed to be directional, so that the user is not affected by glare to the eyes.

This product is available in two design versions:

BOX Design model: The housing of the unit is made of corrosion-protected aluminium, and is provided with an insulated handle made of durable nylon.
LINEAR Design model: This is in the form of a linear design for more convenient operation, with body and grip in insulated rubberized construction.

The unit is designed to be safe and shock-proof, and the product housing is tested to withstand a dielectric breakdown insulation test of 2KV between input terminal and body. The insulation resistance is greater than 500 megohms.

Technical Specifications
• Dimensions (Note: All dimensions are approximate)
o Box model – Dimensions of light head (approx.): 172mm (Length) x 145mm (Width) x 51mm (Height with grill); Length of handle: An additional 125mm
o Linear model – Overall length: 410mm; diameter of grip 45mm
• Input voltage of PowerLED Hand Lamp light head unit: Integral 24VAC/DC (Box model only) OR 230VAC with external Driver unit (NOTE: Order as per requirement)
• Current rating: 350mA (supplied by included Driver);
• Wattage: 6 watts / 9 watts (approx.)
• Colour: Cool White (6500°K)

Contact
Binay Opto Electronics Pvt. Ltd. An ISO 9001:2000 Company 44 Armenian Street Calcutta 700 001, India Telephone: +91 (33) 2242-9082, 2210-3807, 2210-2039 Fax: +91-33-2242-1493

E-mail:info@binayled.com

Web Site:www.binayled.com
