PNpower's 100W high-power LED for constant voltage

Content Dam Leds En Ugc 2011 11 Pnpower S 100w High Power Led For Constant Voltage Leftcolumn Article Thumbnailimage File
33480 0 thumb Date Announced: 10 Nov 2011

100W high power Led Power use in led strips, led modules,guardrail lamp,flood light,street lamp,light word,etc.

Product reference:

Model: PVA-24100PFC; Input voltage:170-250V; Working frequency:50/60Hz; Output voltage: 24V; Output Current:4.16A; Output power:100W; Power factor: >0.95; Efficiency: ≥85%

Working Temp:-25-50oC; Certification:CE/ROHS; Portecion grade:IP67

Product figure:

size:200 x 75 x 45mm

Case material:Aluminum

Wire requirement:Input: white wire,Output brown +blue-

Characteristics of product

High efficiency,save energy, entironment friendly

High stability and low ripple, increase light efficiency and decrease light attenuation

Assure LED stability long lift and light efficiency by constant voltage

Integrity protection,over loading, over voltage, over current

2 years warranty

Certifications for CE(LVD + EMC) & RH

Contact
Zhuhai PNpower Electronic Technology Co.,Ltd Add:6F NO.3 JinShan Road,Xiang Zhou, Zhu Hai,Guang Dong,China HP: 0013631293201 Tel:(86)-756-8650887 Tax:(86)-756-8536474

E-mail:sales2@pnpower.com

Web Site:www.pnpower.com
