LED driver handles rigors of higher voltage off-line illumination

Content Dam Leds En Ugc 2011 01 Led Driver Handles Rigors Of Higher Voltage Off Line Illumination Leftcolumn Article Thumbnailimage File
30096 0 thumb Date Announced: 31 Jan 2011

Dallas, Texas -- Provided in standard SO-8 and high power dissipation exposed pad SO-8 packages, the AL9910 high brightness LED driver from Diodes Incorporated will support universal AC input voltages from 85V to as high as 265V. For interior and exterior off-line lighting products, the exposed pad SO-8 variant in particular helps significantly raise reliability by minimising temperature rise and, through its rugged high voltage process technology, by withstanding input voltage surges of up to 500V. System reliability is further improved by the devices’ in-built over-temperature protection.

Driving LED arrays with a constant current to better control LED brightness, lighting spectrum and lifetime expectancy, the AL9910 will deliver an output of between a few milliamps and 1A via an external MOSFET operating at a resistor programmable switching frequency up to 300kHz. Removing the need for a start-up resistor, a built-in voltage regulator delivers a gate drive to match and protect the switching MOSFET; 7.5V for the AL9910 and 10V for the companion AL9910A.

To extend device flexibility, the high efficiency AL9910 offers two separate dimming inputs for LED brightness control, a linear dimming input controlled by the application of a dc control voltage and a low frequency PWM dimming input accepting an external TTL compatible control signal with a duty ratio of 0-100% and at a frequency of up to a few kHz.

The AL9910 LED driver is priced at $0.60 each in 1k quantities. For further information visit www.diodes.com/products.
