Linear Technology offers 110V LED controller with spread-spectrum frequency modulation

Content Dam Leds En Ugc 2013 09 Linear Technology Offers 110v Led Controller With Spread Spectrum Frequency Modulation Leftcolumn Article Thumbnailimage File
39292 0 thumb Date Announced: 23 Sep 2013

MILPITAS, CA – Linear Technology announces the LT3795, a 110V, high-side current sense DC/DC converter designed to regulate a current or voltage to a constant value, ideal for driving high brightness (HB) LEDs. Its 4.5V to 110V input voltage range makes it appropriate for a wide variety of applications, including automotive, industrial and architectural lighting. The LT3795 uses an external low side N-channel MOSFET and can drive up to 90V of white LEDs from a nominal 12V input, delivering in excess of 50 watts. Spread spectrum frequency modulation reduces EMI emissions, while an internal PMOS switch driver delivers robust short-circuit protection in boost and buck-boost topologies. The LT3795 incorporates a high-side current sense, enabling it to be used in boost, buck, buck-boost or SEPIC topologies. Additionally it offers current both input and output current limiting and monitoring for added reliability and design flexibility. The LT3795 can deliver efficiencies of over 94% in boost mode, minimizing the need for external heat sinking. A frequency adjust pin permits the user to program the frequency between 100kHz and 1MHz, optimizing efficiency while minimizing external component size and cost. Combined with a thermally enhanced TSSOP-28 package, the LT3795 offers a very compact HB LED driver or charger solution.

The LT3795 uses PWM dimming, which delivers constant LED color with dimming ranges of up to 3,000:1. For less demanding dimming requirements, the CTRL pin can be used to offer a 10:1 analog dimming range. Its fixed frequency, current mode architecture offers stable operation over a wide range of supply and output voltages. Robust
open and short-circuit protection maximize overall system reliability, while C/10 detection optimizes both battery and SuperCap charging designs. Additional features include input and output current reporting, frequency synchronization, programmable UVLO and a programmable fault restart timer.

The LT3795EFE is available in a thermally enhanced TSSOP-28 package. Pricing starts at $3.45 each. An extended temperature version or I grade, the LT3795IFE, is also available with pricing starting at $3.86 each. Finally, a high temperature, or H grade, the LT3795HFE is available, the pricing starts at $4.11 each. All prices are in 1,000-piece quantities and all versions are available from stock. For more information, visit www.linear.com/product/LT3795.

Summary of features: LT3795
- 3000:1 True Color PWM™ dimming
- Wide input voltage range: 4.5V to 110V
- Input & output current reporting
- PMOS switch driver for PWM & output disconnect
- Internal spread spectrum frequency modulation
- +/-2% constant voltage regulation
- +/-3% constant current regulation: 0V <= VOUT <= 110V
- Programmable input current limit
- CTRL inputs linearly adjust LED current
- Adjustable frequency: 100kHz to 1MHz
- Programmable open LED protection with OPENLED flag
- Short-circuit protection & SHORTLED flag
- Programmable undervoltage lockout with hysteresis
- Soft-start with programmable fault restart timer
- C/10 detection for battery charging
- Available in 28-lead TSSOP package
