Agilent introduces high-brightness, surface-mount LEDs for automotive lighting

Sep 8th, 2004
Content Dam Leds En Articles 2004 09 Agilent Introduces High Brightness Surface Mount Leds For Automotive Lighting Leftcolumn Article Thumbnailimage File
Agilent Technologies has introduced a series of surface-mount LEDs designed and qualified specifically for automobile interior and exterior lighting applications. These Power PLCC-4-packaged LEDs come in a four-pin, leaded-chip carrier and measure 3.2 mm (H) x 2.8 mm (W) x 1.9 mm (D).

Agilent's Power PLCC-4 package is a form and fit replacement for the popular Osram Power TopLED products and similar automotive PLCC-4 devices from other manufacturers. Typical interior applications for these new LEDs include instrument cluster, central console and switch backlighting. Typical exterior applications include high-mount stop lamps, rear combination lamps, side marker lamps and turn signals.

Agilent's Power PLCC-4 LEDs offer high brightness, a wide selection of colors and a super-wide, 120-degree viewing angle. Agilent's package design, coupled with careful selection of component materials, allows the LEDs to perform with high reliability over the -40 deg.C to +100 deg.C temperature range.

Agilent's package also features an extra-thick (0.21 mm vs. 0.15 mm for the Power TopLED package) lead frame for lower thermal resistance. This feature can reduce the junction temperature of the LED die by 5-7 deg.C for longer life and higher reliability. These LEDs are compatible with IR solder reflow and through-the-wave soldering processes.

US pricing of the Agilent HSMx-A4xx-xxxxx Power PLCC-4 LEDs begins at $0.05 each in 5 million-piece quantities.
